Spot Repair
Designed for quick repair processes
Ideal for part painting
High quality finishes
Control, this is the word that best defines the new SAGOLA Mini Xtreme; why run risks using the wrong tool when it does exist a tool that eases what is difficult?
It always assures the perfect paint-air relation in each situation. It works with the right fan size avoiding the risk of overcharge and inappropriate drop-size.
It reduces mist, saves paint, and perfectly defines the work area.
Light, ergonomic, strong and adapted to the last technologies. Tested and developed on waterborne products.
The fans are designed to obtain the best drying time with the best finish, and always with minimum pressures between 0.5 - 1.0 bar.
Air Cap Mini Aqua | |||
---|---|---|---|
0.80 | Special for waterborne paints. Xtreme finishes | ||
1.00 | Waterborne paints | ||
1.20 | Waterborne paints. High speed |
Air Cap MiniEPA | |||
---|---|---|---|
0.80 | Fine feathering, basecoats | ||
1.00 | Retouching. feathering. Waterborne and solventbased basecoats. Clearcoats and dyes | ||
1.20 | Clearcoats, UV paints, Extremely high finish quality. |
Air Cap Mini HVLP | |||
---|---|---|---|
1.30 | Especially for dyes: wood, tannery products, footwear. | ||
1.40 | Finishes, dyes |
Air Cap Mini TECH | |||
---|---|---|---|
0.60 | Primers for leather with low viscosity products. | ||
1.00 | Lettering and small retouches. |
Weight without cup | 365 g. |
Weight with cup 125 ml. | 445.5 g. |
Weight with cup 500 ml. | 552,75 g. |
Dimensions without cup | 15.6 x 1.8 x 15.8 cm. |
Air inlet couplings | BSP 1/4” M |
Cup capacity | 500 ml |
Deposit with removable anti-drip system | Yes |
Incorporates 100-mesh paint filter | Yes |
Maximum design pressure | 8 bar |
Maximum recommended inlet pressure (working pressure) | 2,0 bar |
Maximum recommended application distance: Mini EPA | 18 - 20 cm. |
Maximum recommended application distance: Mini HVLP | 10 - 15 cm |
Maximum recommended application distance: Mini Tech | 18 - 20 cm. |
Maximum air consumption: Mini EPA | 190 L/min |
Maximum air consumption: Mini TECH | 52 L/min |
Max. air consumption: Mini AQUA | 190 L/min. |
Maximum air consumption: Mini HVLP | 325 L/min |
Materials in contact with the product | INOX, anodised aluminium, POM, Teflon, Nylon |
ATEX | (Ex) II 2 GX |
Code | Version |
---|---|
10111801 | Spray Gun MiniXTREMEG 0.80[miniAQUA] |
10111802 | Spray Gun MiniXTREMEG 1.00[miniAQUA] |
10111803 | Spray Gun MiniXTREMEG 1.20[miniAQUA] |
10111804 | Spray Gun MiniXTREMEG 1.30[MINIHVLP] |
10111805 | Spray Gun MiniXTREMEG 1.40[MINIHVLP] |
10111806 | Spray Gun MiniXTREMEG 0.80[MINIEPA] |
10111807 | Spray Gun MiniXTREMEG 1.00[MINIEPA] |
10111808 | Spray Gun MiniXTREMEG 1.20[MINIEPA] |
10111809 | Spray Gun MiniXTREMEG 1.00[MINIHVLP] |
10111810 | Spray Gun MiniXTREMEG 1.20[MINIHVLP] |
10111811 | Spray Gun MiniXTREMEG 0.60[MINITECH] |
10111812 | Spray Gun MiniXTREMEG 1.00[MINITECH] |
